4 ton I-Beam front axle Material:45#
Tonnage:4T
Distance between kingpins:1627
Distance between leaf springs:860
Kingpin diameter:φ42
Kingpin Inclination:6°
Drop:100

4.3 ton truck steering axle Material:45
Tonnage:4.3T
Distance between kingpins:1727
Distance between leaf springs:851~900
Kingpin diameter:φ38
Kingpin Inclination:7°
Drop:74
Brake specification:Φ400
Rim mounting face distance:2204~2268

Truck Seat-Driver

4.2 ton I-BEAM Material:45
Tonnage:4.2T
Distance between kingpins:1727
Distance between leaf springs:851
Kingpin diameter:φ38
Kingpin Inclination:7°
Drop:φ14

2.5 ton I-BEAM Material:45#
Tonnage:2.5T
Distance between kingpins:1472.4
Distance between leaf springs:760
Kingpin diameter:φ32
Kingpin Inclination:8°
Drop:70+34

Other welded structural parts of lifting machine Turn to use welding body for connection，The steering shaft sleeve is made of special materials，Durable wear resistance，The safety factor is improved.

1.5 ton I-BEAM Material:45#
Rated load:1.5T
Distance between kingpins:1354
Distance between leaf springs:710
Kingpin diameter:φ25
Kingpin Inclination:7.5°
Drop:64+8

2.2 ton I-BEAM Material:45#
Tonnage:2.2T
Distance between kingpins:1359
Distance between leaf springs:750
Kingpin diameter:φ30
Kingpin Inclination:7.5°
Drop:64+5

5.5 ton truck steering axle Material:42CrMo
Tonnage:7.5T
Distance between kingpins:1767
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:3°
Drop:89
Brake specification:Φ420
Rim mounting face distance:2343~2365

5 ton I-Beam Material:42CrMo
Tonnage:4.5~6.1T
Distance between kingpins:1820
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:6.5°
Drop:φ14

7.5 ton I-BEAM Material:42CrMo
Tonnage:7.5T
Distance between kingpins:1767
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:3°
Drop:89

Welded structural parts of lifting machine scissors Turn to use welding body for connection，The steering shaft sleeve is made of special materials，Durable wear resistance，The safety factor is improved.
